| Item | Specification |
|---|---|
| CPU |
AMD Ryzen™ 5 7640HS Processor, 6 cores 12 threads, TSMC 4nm process, Max Frequency 5.0GHz, 6MB L2 Cache / 16MB L3 Cache, TDP 35W–50W |
| GPU | AMD Radeon™ 760M Graphics (8 cores, 2600MHz), RDNA 3 architecture |
| RAM | SO-DIMM ×2, DDR5 4800 MT/s, (Dual-channel), max support 128GB |
| Storage | M.2 SSD ×2, NVMe (PCIe 4.0), expandable up to 8TB (Dual SSD slots) |
| Graphics Output | HDMI 2.0 (4K@60Hz) + DisplayPort (4K@60Hz) + USB4 (supports up to 8K) |
| Network | WiFi 6E (RZ616, 2.4Gbps), Bluetooth 5.2, Dual LAN (RJ45) ×2 (2.5G) |
| Power Supply | DC IN (5.5/2.5mm), 19V / 6.32A 120W |
| Interfaces |
2× USB 3.2 Gen2 (10Gbps, front) 1× USB 3.2 Gen2 (10Gbps, rear) + 1× USB 2.0 (480Mbps, rear) 1× USB 4.0 (40Gbps, supports DP/PD) 1× HDMI 2.0: 4K@60Hz 1× DisplayPort: 4K@60Hz (supports 8K) Audio Jack: 3.5mm, CTIA standard DC Power Input Dual 2.5G Ethernet Ports |
| Operating System | Supports Windows 11 Pro, 14 languages supported (default English) |
| Weight | Bare unit: 528g, Full packaging: 1386g |
| Included Accessories | Power adapter, HDMI cable, VESA mount, manual, warranty card |
| 128.8mm × 127mm × 47.8mm |
GMKtec M6 Ultra
AMD Ryzen™ 5 7640HS
6 cores 12 threads, TSMC 4nm process, Max Frequency 5.0GHz
AMD Radeon™ 760M Graphics
(8 cores, 2600MHz), RDNA 3 architecture
SO-DIMM×2, DDR5 4800 MT/s,
(Dual-channel), max support 128GB
M.2 SSD×2, NVMe(PCIe4.0)
Expandable up to 8TB (Dual SSD slots)
Tripe Screens 8K Display
HDM1 2.0 + DP 1.4 +US8 4.0
WiFi 6E + BT5.2 + Dual LAN
WiFi 6E (RZ616, 2.4Gbps),Bluetooth 5.2,Dual LAN(RJ45)×2 (2.5G)
USB 4.0
(40Gbps, supports DP/PD)
3 modes switch
TDP 35W-54W
AMD Ryzen™ 5 7640HS
6 cores 12 threads, TSMC 4nm process, Max Frequency 5.0GHz
AMD Radeon™ 760M Graphics
(8 cores, 2600MHz), RDNA 3 architecture
SO-DIMM×2, DDR5 4800 MT/s,
(Dual-channel), max support 128GB
M.2 SSD×2, NVMe(PCIe4.0)
Expandable up to 8TB (Dual SSD slots)
Tripe Screens 8K Display
HDM1 2.0 + DP 1.4 +US8 4.0
WiFi 6E + BT5.2 + Dual LAN
WiFi 6E (RZ616, 2.4Gbps),Bluetooth 5.2,Dual LAN(RJ45)×2 (2.5G)
USB 4.0
(40Gbps, supports DP/PD)
3 modes switch
TDP 35W-54W
Power Meets Efficiency
AMD Ryzen™ 5 7640HS Processor
4.3 GHZ,Max Boost | Clock: 5.0GHz
6 Cores(High-performance
Zen architecture)
12 Threads,Process Technology: TSMC 4nm FinFE] Cache: 6MB L2 +16MB L3
Cinebench R23 Multi-Core Score
AMD Ryzen™ 5 7640HS
13029
Intel Core i5-1240P
11268
AMD Ryzen™ 7 7730U
10291
Powerful Graphics Rivaling Dedicated GPU
With a Master Lu score over 1.6 million, this device easily handles AAA titles and esports
games. Enjoy stable high frame rates and smooth gameplay for
animmersive gaming experience.
With 128GB memory and dual M.2 2280 PCle 4.0 slotsthe M6 Ultra runs Excel, Photoshopand other office apps effortlessly whileletting you easily expand storagework and play without limits.
Disassembled design for quick upgrades expandstorage your way, anytime.
UPGRADE OUIET COOLING FANCopper Cooling Fan &Multiple Exhaust vents
Turbo Cooling
Two-way Convection Air Vents
Silent Fan System
Dual LAN (RJ45) – Netzwerkanschlüsse, kompatibel mit Linux, Ubuntu, ESXi und VMware
DUAL 2.5G HIGH SPEED ETHERNET
Lese-/Schreibgeschwindigkeit
2.5Gbps LAN
2.5× Times
1000MbpS LAN
Supports 3-screen 4K display
2*HDMI(4K@60Hz)
1 × Type-C support DP/DATA
Powerful Front USB4.0 Port With Full Functionality
The front USB4.0 port supports ultra-fast 40Gbps data transfer,100W PD charging input, and DP1.4 video output.
Experience faster, more convenient, and versatile connectivi.
ty at your fingertips.
M6 Ultra is equipped with a versatile range of interfaces, including 2x USB 3.2 Gen2 (front) and 1x USB 3.2 Gen2 + 1x USB 2.0 (rear) for fast connectivity. It also features a USB4.0 port (40Gbps, DP/PD support), along with HDMI 2.0 and DisplayPort for up to 8K display output. Additional options include a 3.5mm CTIA audio jack, DC power input, and dual 2.5G Ethernet ports,
